16.00m DOT Tug

MACDUFF "DEE" 16


PRINCIPAL DIMENSIONS
PROPULSION MACHINERY
Length Overall
16.00m
Length B.P.

13.95m

Breadth Mld.
6.50m
Depth Mld.
2.90m
Main Engines
2 x 800hp @ 1800rpm
Propeller
2 x 1700mm
Bollard Pull
20 Tonnes

DECK MACHINERY
CAPACITIES
Mampaey DOT System - 30t SWL

5 Tonne Winch
Windlass



Oil Fuel
11,200 litres
Fresh Water
2,000 litres
Crew
2 men
