In March 2010, The three 23m Mampaey DOT system tugs for Pacific Ocean Engineering and Trading (Poet) are taking shape in China. To a new design from Macduff Ship Design they will be the first vessels to enter service with the DOT 30 system.





23m DOT tug - Macduff DEE - under construction   23m DOT tug - Macduff DEE - under construction
Click photo for design page   Click photo for design page








In March 2010, At a signing ceremony in the offices of Macduff Ship Design on the 5th March the contract for the new 14m harbour workboat for Aberdeen Harbour was concluded between Aberdeen Harbour Board and Macduff Shipyards. The new design has been produced by Macduff Ship Design who will also provide cutting information. Macduff Ship Design are the Harbour Boards project managers for the project which is expected to be completed by the end of February 2011.

Click for Link

Click for Link


Click for Larger image

Click for Larger image



John Watt

Bill Farquhar
Capt Colin Macronald

Capt Ray Shaw
Capt Daniel Stroud
Rory McCann






In March 2010, A 15m steel catamaran workboat for ALLDIVE in Malta is currently under construction using a Macduff Ship Design supplied kit. The vessel is being constructed by a local company -   General Maintenance Ltd - part of the EBCON group.










In February 2010, Macduff Ship Design commenced a concept design for a 27m salmon feed cargo vessel for LCL shipping in Shetland.

LCL Shipping Logo

LCL Logo Click for website

27m Salmon Feed Cargo vessel - Profile


In February 2010, The Design for a proposed new harbour vessel for the States of Guernsey was further developed.

States of Guersey Logo

click for website

15m Harbour Vessel - Profile






In January 2010, Macduff Ship Design has received an order from Blue Anchor to design and produce a design and cutting information for a  6 metre Aluminium Workboat.




In January 2010, British Waterways has signed a contract with Macduff Ship Design for supervision of construction for a new 12.95m River Tug, a Macduff SPEY 13 class, to be build at Manor Marine in Dorset. Macduff Ship Design have produced all of the construction plans for the new vessel and will be providing Manor Marine with the cutting information.


















In January 2010, The Orkney Ferry - "Graemsay" returned to service after a major lengthening carried out by Macduff Shipyards. Now 4.5 m longer at 21.5m length overall her cargo carrying capacity has been greatly increased together with an improvement on her trim and stability. Macduff Ship Design, acting as owners consultants, carried out all the design and drawing work together with stablity calculations.



MV Graemsay after Lengthening Photograph




In December 2009, The 10.85m GRP Catamaran research vessel "Actinia" was handed over to her owner - University Marine Biological Station Millport - by her builder - Seaway Marine. Based on a Gemini moulding the vessel is comprehensively equipped to carry out sampling, trawling, creeling, dive support, surveying and as a platform for educational studies. Macduff Ship Design acted as Owners Project Managers and designers throughout the tender process and construction stages. This is the second research vessel that Macduff has designed for Millport.




In November 2009, Macduff Ship Design received an order from Alldive in Malta to design a 15m Catamaran dive support vessel. To be constructed of steel, Macduff will also supply the kit for fabrication in Malta. Based on the 12.44m "Lonabrak" the vessel will be used for ship cleaning / maintenance and general harbour work. The order was secured through LEONARD BUGEJA in Malta who has been working with Macduff Ship Design on various projects.

15m Cat Dive Support Vessel - Illustration




In October 2009, The recently commissioned 16m 'NESS' Harbour Tug - "Sally Mcloughlin" - is seen carrying out her very first towing contract. She towed the visiting Canadian frigate - HMCS Montreal (7000 grt) - in and out of Belfast Harbour during a courtesy call.

16m NESS Tug Towing HMCS Montreal




In October 2009, Boustead Yachts in Malaysia completed two Macduff "FORTH" 13m tugs - the "BHT 23" and "BHT 24". Based on the successful "Ugie Runner" hull form they are equipped with conventional tow hooks and a unique moveable bow fender for pushing submarines. Fitted with twin Volvo 450 Hp engines and 1600mm propellers and nozzles supplied by Kort Propulsion they will be used by Boustead for ship handling duties at their own shipyard.



13m FORTH Tug Completion         13m FORTH Tug completion






In October 2009, The 16m 'NESS' Tug, "Sally Mcloughlin" , carried out her official trials and was handed over to her owner - John Mcloughlin and sons of Larne, N.Ireland. The vessel surpassed all expectations and achieved a bollard pull ahead of 23 tonnes (average) and astern of 18 tonnes. A remarkable set of performance figures for a 16m vessel. Her free running speed was an average of 10.3 knots in offshore conditions. Plough dredging trials were also successfully carried out highlighting the versatility of the vessel.



16m NESS Tug on trials 16m NESS Tug on trials

16m NESS Tug completion 16m NESS Tug completion




In September 2009, Macduff Ship Design signed a contract with the Akdeniz Shipyard in Adana, Turkey, for the supply of tug designs for the company's 13m 'NESS class,' "Fair Maid" and 8.95m Forth class, "Sea Helper". Macduff will provide technical information, drawings, stability calculations and cutting information.

13m NESS Class          8.95m FORTH Class
13m

8.85m
Signing Ceromony at Akdeniz Shipyard

D.S.Cameron, Managing Director, Macduff Ship Design and N. Metin AKBASOGLU, Chairman, AKDENIZ Shipyards.


In September 2009, Macduff Ship Design was awarded a contract from Aberdeen Harbour Board to provide a complete design and drawing package for a new design 14m harbour workboat. The vessel will be capable of plough dredging, rubbish collection, dive support, surveying and general harbour maintenance.

14m harbour workboat- Illustration


In September 2009, The 16m 'NESS' Tug, "Sally Mcloughlin" , has successfully carried out preliminary sea trials.

16m NESS Tug on preliminary trials   16m NESS Tug on preliminary trials




In September 2009, The "Sally Mcloughlin" - the first MACDUFF "NESS" a 16m Harbour tug / Workboat - was launched. Commissioning and trials will now take place prior to her handover later in September.



16m NESS Tug Launch     16m NESS Tug Launch     16m NESS Tug Launch

16m NESS Tug Launch




In August 2009, MMS Shiprepair in Hull commissioned Macduff Ship Design to produce detailed construction plans for a new 8m aluminium waste collection vessel.



8m Waste Vessel - 3d Illustration




In August 2009, The 16m "NESS" class tug - "Sally Mcloughlin" - is scheduled for launching and handover in September with painting all complete.

16m NESS Tug completion       16m NESS Tug completion

Click images of more information




In July 2009, Boustead Yachts in Malaysia are now in the outfitting stage of two 13m "Forth" Class harbour tugs. Macduff Ship Design have provided complete drawing and cutting information packages for these vessels.



13m FORTH Tug


In July 2009, Recently launched at the Dalmont Shipyard in Croatia, the 23.9m "Nebeski" and "Beli" are identical single rig trawlers for local owner  Romeo Mikicic. Built to a new design for Adriatic waters they are also identical to the "Moni" launched by Tehnomont Shipyard, Pula, Croatia in January 2009.



23.9m Trawler        23.9m Trawler




In June 2009, Macduff Ship Design show cased it's new "Multi-Mac" design, produced for Dunberry Marine, at the Seawork Exhibition. Macduff and Dunberry held discussions with several shipyards who are bidding for the contract.





Multi Cat Profile   SeaWork 2009

Click Image to open 3d Pdf

Pdf Reader 8.0 of Higher required

File size 1.52 mb


Damian Breckon and Chris Duncan of Dunberry Marine, Ricardo Garcia of Astilleros Armon and Donald Cameron of Macduff Ship Design.






In May 2009, Macduff Ship Design announces another new addition to its tug/ workboat range. Designated a Macduff "Ness" Class workboat the vessel has a hull length of 27m, moulded breadth of 11m and has a triple screw installation. Featuring a 240 T/M deck crane, large capacity anchor/ towing winch and extensive crew/ technician accommodation the vessel will be capable of towing, pushing, anchor handling, civil engineering support, surveying and cargo carrying.

27m NESS Class workboat - profile

Click illustration for more information




In May 2009, Two, 22m, residential barges for the River Thames have been constructed by TMP Group in Middlesex. Macduff Ship Design provided the cutting information and Steel Kits for the craft based on outline drawings from Clive Chapman Architects. A third craft is under construction.



Residential Barge                Residential Barge






In April 2009, The 28.95m "Endeavour IV" completed a very successful maiden trip, landing 1000 boxes of prime quality deep water fish. Built by Macduff Shipyards to a new design produced jointly by Macduff Ship Design and Macduff Shipyard with input from the Polish tank testing facility - CTO - the vessel proved her seakeeping and overall performance to the complete satisfaction of her skipper / owner.



28.95m      28.95m




In April 2009, The 16m Macduff "Ness" tug for John Mcloughlin is now at an advanced stage of construction.

16m NESS Tug - under construction          16m NESS Tug - under construction






In March 2009, Macduff Ship Design signed a contract with Sepehr Sea South Company of Tehran for the supply of complete design packages for the construction of four 13m mooring boats and two 15.9m multi purpose workboats. The mooring boats will be based on the "Fair Maid" design, a Macduff "Ness" class of vessel and the workboats on the "Boyne Protector" - a general purpose vessel designed for Drogheda Port in Ireland.



Signing Ceremony: Mr Kambiz Arab & Mr Donald S. Cameron

Signing Ceremony

Left: Mr Kambiz Arab, Managing Director of Sepehr Sea South Shipyard.      Sepehr Sea South Company Logo
Right: Mr Donald S. Cameron of MSD Macduff Ship Design Logo




In March 2009,  Construction is advancing on the 20m Aluminium Pilot Boat being built by Tyovene in Finland for Orkney Harbours. Based on a concept design produced by Macduff Ship Design, who are acting as owners naval architects / technical advisors, Tyovene have been responsible for the production Drawings.



20m Aluminium Pilot Vessel - under construction      20m Aluminium Pilot Vessel - under construction



Tyovene Logo




In March 2009,  On the 13th March the 27.9 m Trawler "Ocean Venture II" was launched from the Armon shipyard in Vigo Spain.  Built to the order of Neil and Ross Minihane the vessel is scheduled to run trials in April.



Ocean Venture II before launch         Ocean Venture II launched
