12.00m Harbour Tug
Technical Drawing
PRINCIPAL DIMENSIONS
PROPULSION MACHINERY
Length Overall
12.00m
Length B.P.

9.97m
Breadth Mld.
4.70m
Depth Mld.
2.25m
Main Engines
2 x 450hp @ 1800rpm
Propeller
1500mm
Bollard Pull
13.4 Tonnes

DECK MACHINERY
CAPACITIES
Towing Hook 15 Tonne





Oil Fuel
6,000 litres
Fresh Water
500 litres
Crew
2 men
Illustration
