14.00m Line Handler

MACDUFF "TWEED" 14

Technical Drawing
PRINCIPAL DIMENSIONS
PROPULSION MACHINERY
Length Overall
14.00m
Length B.P.

11.80m
Breadth Mld.
5.50m
Depth Mld.
2.70m
Main Engines
2 x 450hp @ 1800rpm
Propeller
1500mm
Bollard Pull
13.4 Tonnes

DECK MACHINERY
CAPACITIES
Towing Hook 15 Tonne




Oil Fuel
8,000 litres
Fresh Water
1,000 litres
Crew
2 men
Illustration
