8.95m Harbour Tug

MACDUFF "FORTH" 9

Technical Drawing
PRINCIPAL DIMENSIONS
PROPULSION MACHINERY
Length Overall
8.95m
Length B.P.

7.85m

Breadth Mld.
3.80m
Depth Mld.
1.75m
Main Engines
103hp @ 1800rpm
Propeller
800mm


DECK MACHINERY
CAPACITIES
Towing Winch

Oil Fuel
1,000 litres
Crew
2 men



Illustration


Click to open 3d pdf

Adobe Reader 8.0 or higher required

File Size 3.99 MB
